F2000 M-Trigger Classic

Features

The F2000 M-Trigger Classic is a drop-in microswitch trigger system designed by Shadow Regime Airsoft. Upgrade your F2000 with better trigger response, shorter trigger travel, and a mosfet of your choice.

Included in box

• Fully assembled trigger unit (springs included)

• SR PVC velcro patch

• Perun AB++ mosfet pre-installed if selected

Trigger

• Fixes semi-auto problems common in airsoft F2000s

• Reduces semi auto trigger pull and reset for quicker semi-auto shots

• Keeps 2-stage trigger functionality: initial trigger pull for semi, full trigger pull for full auto

• Low resistance wiring and mosfet improves trigger response and fire rate

• Removable semi-only mod available

• Everything 3D printed in high strength Fiber Nylon plastic

• Japanese Omron microswitch rated to 1 million trigger pulls

Mosfet Functions (AEG only)

• Available with Perun AB++ mosfet pre-installed

  • Adjustable active braking (5 settings or off)

  • Adjustable precocking (8 settings or off), long press trigger to reset spring for storage

  • Change full auto to 2-5 round burst

  • Adjustable rate of fire reduction (5 settings down to 70% speed or off)

  • LiPo alarm (on/off)

• Compatible with below mosfets if soldering your own

  • Perun AB++, Gate X-ASR, Gate NanoASR, Gate NanoHard, Gate MERF, Gate Warfet

Compatibility and Installation

• Easy installation

  • Direct drop-in replacement of original trigger unit

  • No soldering if ordered with mosfet installed

  • No opening the gearbox

• Compatible with pre-2019 G&G F2000’s only

  • Not compatible with post-2019 G&G F2000’s with G&G’s ETU trigger system. The new F2000 M-Trigger Evo IS compatible though!

  • Not compatible with Cybergun F2000 which uses a V3 gearbox. We have Gate and Perun V3 mosfets that will work instead.

• We recommend our M-Trigger Evo for Wolverine Hydra HPA users

• Compatible with brushless motors

• Compatible with DSG gearboxes

Upgrade to the M-Trigger Evo to get:

• Exclusive pivot-style trigger in custom colors

• Tactical selector switch in custom colors

• Extremely smooth trigger pull with the removal of the trigger bar

• Adjustable trigger pull and trigger stop

• Custom fire modes on each selector position, including binary trigger

• Electronic cycle detection to eliminate gearbox jams and incomplete cycles

• Compatible with every G&G F2000 and Wolverine Hydra HPA

3D Files

Download Part Files

All of Shadow Regime’s custom designed parts will have their files available for free download or purchase at our page on thangs.com

• STL and 3MF files included

• STEP files included for direct editing in CAD software

• 3MF print files included to print with the same settings we do (Bambu Studio + Bambu PAHT)

3D View

Select “continue in browser” if needed. You can rotate the model here and take any measurements you need.

Mobile users: open in new window
